您的當前位置:首頁 > 產品中心 > 車規級穩壓管(LDO)
車規級穩壓管
產品型號:TPS799-Q1
產品展商:

簡單介紹

The TPS799xx-Q1 family of low-dropout (LDO) low-power linear regulators offers excellent AC performance with very low ground current. High power-supply rejection ratio (PSRR), low noise, fast start-up, and excellent line and load transient response are provided while consuming a very low 40-μA (typical) ground current. The TPS799xx-Q1 is stable with ceramic capacitors and uses an advanced BiCMOS f

詳情介紹
Output optionsFixed OutputIout (Max) (A)0.2Vin (Max) (V)6.5Vin (Min) (V)2.7Vout (Max) (V)6.4Vout (Min) (V)1.2Fixed output options (V)1.2, 1.5, 1.8, 2.5, 2.7, 3.3Noise (uVrms)30Iq (Typ) (mA)0.04Thermal resistance θJA (°C/W)74RatingAutomotiveLoad capacitance (Min) (μF)2Regulated outputs (#)1FeaturesEnableAccuracy (%)2PSRR @ 100 KHz (dB)38Dropout voltage (Vdo) (Typ) (mV)100Operating temperature range (C)

-40 to 125
